CHAPTER
29
5
MOTU Audio Console
OVERVIEW
MOTU Audio Console gives you access to basic
UltraLite-mk3 hardware settings, such as sample
rate, clock source and more.
Accessing the UltraLite-mk3 settings . . . . . . . . . . . . . . . . 29
‘General’ tab Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Sample Rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Clock Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Samples Per Buffer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Wave support for legacy (MME) software . . . . . . . . . . . . 32
Enable Pedal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
‘UltraLite-mk3’ tab settings . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Phones Assign . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Main Out Assign . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Return Assign. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Disable Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
ACCESSING THE ULTRALITE-MK3 SETTINGS
There are several ways to access MOTU Audio
Console settings:
■
From the Windows Start menu, choose
Programs>MOTU>MOTU Audio Console
■
In Cubase or Nuendo, open the Device Setup
window, click
VST Audio System
and choose
MOTU Audio ASIO
from the
Master ASIO Driver
menu as shown below
.
Then click the
MOTU Audio
ASIO
item in the list
and click the
Control Panel
button.
■
From within other ASIO-compatible programs,
refer to their documentation.
■
From the front panel LCD (see chapter 6,
“UltraLite-mk3 Hybrid Front Panel Operation”
(page 35)).
General tab settings
The General tab provides settings that apply
globally to all connected MOTU FireWire
interfaces.
UltraLite-mk3 tab settings
The UltraLite-mk3 tab provides settings that apply
to a specific UltraLite-mk3 interface. If you have
several UltraLites (or other MOTU FireWire audio
interfaces) connected, you’ll see a separate tab for
each one.
