Pioneer Dj DDJ-FLX4 Portable 2-Channel rekordbox DJ and Serato Controller (Graphite) - Manual (Page 159)

Additional information
159
En
Specifications
General – Main Unit
Rated power supply
When a USB power adapter is used ...............................DC 9 V, 3 A
When a USB bus power is used...............................DC 5 V, 500 mA
Main unit weight........................................................... 2.1 kg (4.6 lbs.)
Max. dimensions (W × D × H)
.................................482 Ч 272.8 Ч 59.2 mm (18.98" Ч 10.74" Ч 2.33")
Tolerable operating temperature...... +5 °C – +35 °C (+41 °F – +95 °F)
Tolerable operating humidity................. 5 % – 85 % (no condensation)
Audio Section
Sampling rate .............................................................44.1 kHz/48 kHz
A/D, D/A converters ..............................................................16bit/24bit
Frequency characteristic
USB , MIC ..................................................................20 Hz – 20 kHz
S/N ratio (rated output, A-WEIGHTED)
USB ........................................................................................103 dB
Total harmonic distortion (20 Hz to 20 kHz BW)
USB ...................................................................................... 0.005 %
Input impedance
MIC ............................................................................... 3 k Ω or more
Output impedance
MASTER ........................................................................ 1 k Ω or less
Headphones ................................................................... 10 Ω or less
Rated output level / Load impedance
MASTER .................................................................. 2.1 Vrms/10 k Ω
Input / Output terminals
MIC
input terminal
1/4” TS jack ............................................................................... 1 set
