10
No. Component Description
1 Port Selection
Pushbuttons
For manual port selection ( see Manual Switching, page 14 )
• Press one of the port selection pushbuttons for less than two seconds to bring the KVM,
USB hub and audio focus to the computer connected to its corresponding port
• Press one of the port selection pushbuttons for longer than two seconds to bring only the
KVM focus to its corresponding port
• Press one of the port selection pushbuttons twice to bring the audio focus to the computer
connected to its corresponding port
• Press port selection buttons 1 and 2 simultaneously for 2 seconds to implement Auto
Scan Mode. ( See Auto Scan Mode section for more details, page 21 )
2 Mode Selection
Pushbutton
The LEDs will light up DIM Orange to indicate its mode and status
• Press to toggle between Extension and Matrix Mode
◦ Extension Mode – Content of the focused computer will be displayed on both monitors
◦ Matrix Mode – Content of two computers will be displayed individually on two monitors
• Press and hold mode selection pushbutton and the remote port selector pushbutton
before powering on to enter Firmware Upgrade mode. ( See Firmware Upgrade Mode
section, page 32 )
3 Port LEDs The Port LEDs are built into the Port Selection Pushbuttons. The top LEDs are KVM port
LEDs, the middle LEDs are Audio LEDs, the bottom LEDs are USB LEDs:
KVM
• LED lights up DIM Orange to indicate that the computer attached to the corresponding
port is connected
• Selected LED lights up Bright Orange to indicate that the computer attached to the
corresponding port is the one that has the KVM FOCUS (Selected)
• LED flashes to indicate that the computer attached to its corresponding port is being
accessed under Auto Scan Mode
Audio
• LED lights up DIM Green to indicate that the audio is being outputted from the
corresponding port(s)
USB
• LED lights up DIM Green to indicate that the computer attached to the corresponding port
has access to the USB Peripherals
4 Audio Ports Microphone and speakers connected into these audio ports have priority over those connected
in the rear side panel of the GCMS1922
5 USB Hub USB peripherals (USB drives, printers, etc.) can be connected into this port. The built-in USB
3.1 Gen 1 ports feature 5 Gbps data transfer rates for compatible USB peripherals
6 Console Ports The cables from the HDMI monitors, USB keyboard, USB mouse, speakers and microphone
are connected into these ports
Each connector is marked with an appropriate icon to indicate its use
7 KVM Ports The KVM cables from the computers are connected into these ports. Each KVM port section
is comprised of a microphone jack, speaker jack, USB type B socket and two DisplayPort
connectors
8 Power Jack The power adapter cable is connected into this jack
9 Remote Port
Selector Jack
The remote port selector is connected into this port
