IOGear 2-Port 4K Dual View DisplayPort Matrix KVMP Switch - Manual (Page 36)

36
Specifications Chart
Computer Connections 2
Port Selection Pushbuttons, Hotkey, Mouse Wheel (mouse wheel port switching only works
with 3-key USB mouse wheel in emulation mode), Remote Port selector or
Mouse cursor (Under Matrix Mode and Crossover Switching is enabled)
Console Connectors
Monitor 2 x HDMI
Keyboard 1 x USB Type A
Mouse 1 x USB Type A
Audio 2 x 3.5mm Mini Stereo Jack (Green; Front and Rear)
Microphone 2 x 3.5mm Mini Stereo Jack (Pink; Front and Rear)
CPU Connectors
Monitor 2 x DisplayPort
Keyboard & Mouse 2 x USB 3.0 Type B
Audio 2 x 3.5mm Mini Stereo Jack (Green)
Microphone 2 x 3.5mm Mini Stereo Jack (Pink)
Connectors
Remote Port Selector 1 x 2.5 mm Jack Female
USB 1 x USB 3.0 Type A (Blue; Front), 1 x USB 3.0 Type A (Blue; Rear)
Power 1 x DC Jack
Switches 3 x Pushbutton
Port Selection 3 x Pushbutton
LEDs
KVM 2 x Orange
Audio 2 x Green
USB Peripherals 2 x Green
Mode 2 x Orange
Emulation
Keyboard USB
Mouse USB
Video Resolution Up to 4096 x 2160 @60 Hz
Scan Interval 1~99 seconds (5 seconds default)
Power Consumption DC 12V: 11.58W : 97BTU
Environment
Humidity 0~80% RH, Non-condensing
Operation Temperature 32~ 104 F (0~40 C)
Storage Temperature -4~ 140 F (-20~ 60 C)
Housing
Case Metal
Dimensions 10.3x 2.9x 1.7 in. (26x 7.4x 4.2 cm)
