Alternate Port Switching Keys
The port switching activation keys can be changed from clicking [Scroll Lock] key twice
( [Scroll Lock][Scroll Lock] ) to clicking [Ctrl] key twice ( [Ctrl][Ctrl] ).
To change the port switching activation keys:
1. Invoke HSM, see page 22
2. Press and release [T] key
Note:
This procedure is a toggle between the two methods. To revert back to the default [Scroll Lock][Scroll
Lock] method, invoke HSM, then press and release [T] key again.
Keyboard Operating Platform
The default port configuration of GCMS1922 is for a “Windows” compatible keyboard
operating platform. If the Windows compatible keyboard has been used at console side
and you have a Mac or Sun machine attached with GCMS1922, you can change the port’s
keyboard operating platform, so the Windows compatible keyboard emulates the Mac or Sun
keyboard.
1. Bring the KVM focus to the port you want to set
2. Invoke HSM, see page 22
3. Press and release the appropriate Function key (see the table below). After completing
this procedure, GCMS1922 automatically exit HSM.
Function Key Operation
[F1] Sets GCMS1922 to Extension Mode so that it can work under
special operating systems as a standard (104 key) keyboard.
[F2] Enable Mac keyboard emulation, see page 30 for details.
[F3] Enable Sun keyboard emulation, see page 31 for details.
[F10] Enable Windows keyboard emulation
List Switch Settings
To see a listing of the current switch settings:
1. Open a text editor or word processor and place the cursor in the page window
2. Invoke HSM, see page 22
3. Press and release [F4] to display the settings
