Features – IOGear 2-Port 4K Dual View DisplayPort Matrix KVMP Switch User Manual
Page 7
7
• Dual Monitor console controls for two computers and two USB3.0 peripherals
• Dual Operation Modes
◦
Extension Mode – access one PC at a time and allows content of the current focus
computer to be displayed over two monitors
◦
Matrix Mode – allow contents of two computers to be displayed separately on two
monitors regardless the computer focus
• Port switching via pushbuttons, hotkeys, mouse wheel, mouse cursor and remote
port selector
• Mouse Crossover Switching – Under the Matrix Mode, the mouse cursor can drag
across two monitors for instant switching between the two connected computers
• Independent Switching of KVM, USB, and Audio focus
• Superior 4K video quality – 4K UHD (3840x2160 @60Hz) and True 4K (4096x2160
@60Hz)
• DisplayPort 1.2, HDMI 2.0 and HDCP compliant
• 2-Port USB 3.1 Gen 1 With Super Speed 5 Gbps transfer rate
• Audio Mixer – enable mixing of up to two audio sources and output the mixed audio
to the speakers
• Support 7.1 HD audio through DisplayPort
• Full bass response for high quality 2.1 channel surround sound systems
• Power on detection – if a computer is powered OFF, the GCMS1922 will
automatically switch to the next powered ON computer
• Mouse emulation or bypass feature supports most mouse drivers and multifunction
mice
• Keyboard emulation or bypass feature supports most multifunction keyboard
• Multi-platform support
• Multilingual Keyboard mapping supports English, French, German and Japanese
Keyboards
• Mac keyboard support and emulation
• Auto Scan Mode feature to monitor all computers
Note:
1.
Mouse switching supported by mouse emulation mode using a USB 3-button mouse wheel
2.
HD audio through DisplayPort cannot be switched independently
