Audio Mixer
The Audio mixer feature enables mixing up to two audio sources and output the mixed audio
to the speakers. To enable / disable the audio mixer mode:
1. Invoke HSM, see page 22
2. Press
[A][O] [Enter]
Note:
1.
This procedure is a toggle. Repeat to revert to the original setting.
2.
Digital audio mixing is unavailable on GCMS1922. Please use analog audio cable connections for
audio mixing.
Automatic Audio Mixer
With Automatic Audio Mixer enabled, when GCMS1922 is under Matrix Mode, the audio
sources are mixed automatically, and audio sources are separated when under Extension
Mode. To enable the automatic audio mixer:
1. Invoke HSM, see page 22
2. Press
[A][P] [Enter]
Manual Audio Mixer
Manual Audio Mixer will not change the Audio Mixer setting when switching between
Extension Mode and Matrix Mode. To enable the manual audio mixer:
1. Invoke HSM, see page 22
2. Press
[A][R] [Enter]
EDID
EDID Is the data that contains monitor’s information and used to communicate with
video source. GCMS1922’s EDID selection allows to set a pre-programmed EDID for the
connected monitor. To implement an EDID setting:
1. Invoke HSM, see page 22
2. Press
[V][n] [Enter]
na
Description
1
ses the EDID of the monitor connected to PortA and B, this
is the default settings.
2
Sets the EDID to FHD which is 1920 x 1080 @60Hz
3
Sets the EDID to 4K HD which is 3840 x 2160 @60Hz
4
Sets the EDID to 4K DCI which is 4096 x 2160 @60Hz
