21
Hotkey Function
[Scroll Lock] [Scroll Lock] [K][U][S] [Enter]
Example:
1. Click [Scroll Lock] twice.
2. Click [K].
3. Click [U].
4. Click [s].
5. Click [Enter].
Bring the keyboard, mouse, USB peripheral
and audio to the next port.
Auto Scan Mode
Under “Extension Mode” , GCMS1922’s Auto Scan feature allows you to monitor computer
activities without switching from port to port manually. This feature automatically cycles the
KVM focus through the computer ports at regular intervals. See the table below for details
When Auto Scan is in effect, only Auto Scan Mode compliant keystrokes and mouse clicks
work. Ordinary keyboard and mouse functions are suspended. Click [Esc] or Space Bar to
exit Auto Scan Mode to regain normal control of the console.
Although video focus switches from port to port, keyboard, mouse, and USB focus do not
switch. They remain on the port when Auto Scan began.
Hotkey Function
[Scroll Lock] [Scroll Lock] [A][Enter]
Example:
1. Click [Scroll Lock] twice.
2. Click [A].
3. Click [Enter].
Invokes Auto Scan
The KVM focus cycles from port to port at 5
seconds (default) intervals.
[Scroll Lock] [Scroll Lock] [A][n] [Enter]
Example:
1. Click [Scroll Lock] twice.
2. Click [A].
3. 3Click [9].
4. Click [Enter].
The KVM focus cycles from port to port at [n]
second intervals.
The [n] stands for the number of seconds that
the GCMS1922 should dwell on a port before
moving on to the next port. Replace [n] with a
number between 1 and 99 when entering this
hotkey combination.
