18
IOGEAR’s GCMS1922 provides an extensive, easy-to-use, hotkey function for convenience
in controlling and configuring KVM installation from the keyboard. Hotkeys provide
asynchronous (independent) switching of the KVM, USB hub and audio focus. Therefore,
the users can give one computer the KVM focus, and another the USB hub focus or the
audio focus.
Port Switching
All port switching begins by clicking [Scroll Lock] twice. The table below describe the
actions that each combination performs.
Note:
If using the [Scroll Lock] key conflicts with other programs running on the computer, the [Ctrl] key
can be used, instead. See Alternate Port Switching Key at page 23 for details.
Hotkey Operation
Cycling Through the Ports
Hotkey Function
[Scroll Lock][Scroll Lock][Enter]
Example:
1. Click [Scroll Lock] twice.
2. Click [Enter].
Brings the KVM, USB hub and Audio focus to the
next port (1 to 2; 2 to 1).
Note: The KVM, USB hub and Audio focus all go to this
port even if they were on different ports to begin with.
[Scroll Lock][Scroll Lock][K][Enter]
Example:
1. Click [Scroll Lock] twice.
2. Click [K].
3. Click [Enter].
Brings only the KVM to the next port. The USB
hub and Audio focus remain where they are.
[Scroll Lock][Scroll Lock][U][Enter]
Example:
1. Click [Scroll Lock] twice.
2. Click [U].
3. Click [Enter].
Brings only the USB hub to the next port. The
KVM and Audio focus remain where they are.
[Scroll Lock][Scroll Lock][S][Enter]
Example:
1. Click [Scroll Lock] twice.
2. Click [S].
3. Click [Enter].
Brings only the Audio to the next higher port
The KVM and USB hub remain where they are.
