6
IOGEAR’s GCMS1922 2-Port 4K Dual View DisplayPort Matrix KVMP Switch with USB
3.0 Hub and Audio takes KVM to a whole new level by combining KVM, Matrixing, Mouse
Crossover Switching, dual video interface, 2-Port USB 3.0 hub and 2.1 Channel audio.
It provides up to Cinema 4K – 4096x2160 @60Hz resolution that displays high-definition
video while delivering premium sound for music, movies, and gaming.
The GCMS1922 allows users to access two DisplayPort computers from a single USB
Keyboard, USB mouse, and dual HDMI monitors. In addition to the front panel pushbutton
and hotkeys, IOGEAR’s GCMS1922 offers mouse wheel switching as well as a remote port
selector to change ports.
With the built-in Matrix function, the GCMS1922 provides two operation modes – Extension
and Matrix. In Extension Mode, content of the focused computer can be displayed over
both monitors, and in Matrix Mode two computers can be displayed individually on either
monitor. When in Matrix Mode, the Mouse Crossover Switching allows users to simply drag
the mouse cursor across the two monitors and will instantly switch to the other connected
computer.
With a built-in USB 3.1 Gen 1 hub, each connected computer can transfer up to
SuperSpeed 5 Gbps to all connected peripherals. The GCMS1922’s independent switching
feature allows the KVM to focus on one computer while the USB peripheral and audio
focus on another. This allows for a much higher level of multi-tasking for professional
environments such as IT Programing, Graphic Designing, Video Editing, Financial Trading
and Remote Working.
Introduction
• 1 x 2-Port 4K Dual View DisplayPort Matrix KVMP Switch KVMP Switch
• 2 x DisplayPort KVM Cable set
• 1 x Remote Port Selector
• 1 x Power Adapter
• 1 x Power Cord
• 1 x Quick Start Guide
• 1 x Warranty Card
Please verify that all components are present, and nothing was damaged in shipping.
If you encounter a problem, contact your dealer.
Read this manual thoroughly and follow the installation and operation procedure to
prevent any damage to the unit, and/or any of devices connected to it.
Package Contents
