English 78
ADDITIONAL INFORMATION
Specifications
Optical Description
Lens type 1.6x 1.15x Fixed
Throw ratio 1.25~2.0 0.65~0.75 0.63
Maximum resolution WUXGA WUXGA WUXGA
Zoom & focus adjustment Power Power Power
Image size (diagonal) 50”~300” 50”~1000” 40”~300”
Electrical Description
Inputs
- HDMI 1 v2.0/4K
- HDMI 2 v2.0/v1.4a
- VGA-IN
- 3D SYNC IN
- USB Type-A x1
- AUDIO-IN 3.5mm
Outputs
- HDMI OUT
- 3D SYNC OUT
- AUDIO-OUT 3.5mm
- 12V OUT Trigger
Control
- Wired IR
- HDBaseT
- RJ-45 (support web control)
- RS232
Color reproduction 1073.4 Million color
Scan rate
- Horizontal scan rate: 15.38 ~ 91.15 KHz
- Vertical scan rate: 24 ~ 85 Hz (120 Hz for 3D feature)
Built-in speaker 2x 10W speakers
Power requirement 100 - 240V ±10%, AC 50/60Hz
Power Consumption
- Normal mode: 520W ± 15% @ 110Vac / 505W ± 15% @ 220Vac
- ECO mode: 265W ± 15% @ 110Vac / 260W ± 15% @ 220Vac
Input current 6.5A
Installation orientation Front, Rear, Ceiling-top, and Rear-top
Dimensions
(W x D x H)
1.6x lens model:
- 486 x 432.5 x 176.0 mm (w/o feet)
- 486 x 432.5 x 185.5 mm (with feet)
1.15x lens model:
- 486 x 427.5 x 176.0 mm (w/o feet)
- 486 x 427.5 x 185.5 mm (with feet)
Fixed lens model:
- 486 x 417.4 x 176.0 mm (w/o feet)
- 486 x 417.4 x 185.5 mm (with feet)
Weight 14 ± 0.5 Kg
Environmental conditions Operating in 5 ~ 40°C , 10% to 85% humidity (non-condensing)
Note: All specifications are subject to change without notice.
