ADDITIONAL INFORMATION
Note:
Some commands are not supported, it depends on models
.
Level 1
Level 2
Level 3
Level 4
Level 5
Level 6
n value
Read Command
Command
Command
Pass
CMD
CMD Value
CMD
Write Command
sp
ac
e
Set
Para.
Regulatory Model
~XX151
4
O k
DAZUKNZT
DAZUKNZTST
DAZUBNZT
DAZUBNZTST
Software Version
~XX122
1
O k nnnnnnn (Software Version)
Fan 1 Speed
0000~9999
~XX351
1
O k 0000~9999
Fan 2 Speed
0000~9999
~XX351
2
O k 0000~9999
Fan 3 Speed
0000~9999
~XX351
3
O k 0000~9999
Fan 4 Speed
0000~9999
~XX351
4
O k 0000~9999
Fan 5 Speed
0000~9999
~XX351
5
O k 0000~9999
Fan 6 Speed
0000~9999
~XX351
6
O k 0000~9999
Fan 7 Speed
0000~9999
~XX351
7
O k 0000~9999
Fan 8 Speed
0000~9999
~XX351
8
O k 0000~9999
Fan 9 Speed
0000~9999
~XX351
9
O k 0000~9999
Fan 10 Speed
0000~9999
~XX351
10
O k 0000~9999
Fan 11 Speed
0000~9999
~XX351
11
O k 0000~9999
Fan 12 Speed
0000~9999
~XX351
12
O k 0000~9999
Fan 13 Speed
0000~9999
~XX351
13
O k 0000~9999
Fan 14 Speed
0000~9999
~XX351
10
O k 0000~9999
System Temperature
~XX352
1
O k 0000~9999
Info String
~XX150
1
O k abbbbbccddddee
Native Resolution
~XX150
2
O k nnn..nn (e.g. Ok1920x1080)
Main Source
~XX150
3
O k nnn..nn (e.g. OkHDMI)
- Resolution
~XX150
4
O k nnn..nn (e.g.Ok1920x1080)
- Signal Format
~XX150
5
O k nnn..nn
- Pixel Clock
~XX150
6
O k nnn..nn
- Horz Refresh
~XX150
7
O k nnn..nn
- Vert Refresh
~XX150
8
O k nnn..nn
Sub Source
~XX150
9
O k nnn..nn
- Resolution
~XX150
10
O k nnn..nn (e.g. Ok1920x1080)
- Signal Format
~XX150
11
O k nnn..nn (e.g. OkHDMI)
- Pixel Clock
~XX150
12
O k nnn..nn
- Horz Refresh
~XX150
13
O k nnn..nn
- Vert Refresh
~XX150
14
O k nnn..nn
Light Source Mode
~XX150
15
O k nnn..nn
Active
~XX150
16
O k 1
Eco.
~XX150
16
O k 0
Communication
~XX150
16
O k 3
Off
~XX150
17
O k 0
On
~XX150
17
O k 1
System Temperature
~XX150
18
O k nnn..nn (e.g. Ok48)
Refresh rate
~XX150
19
O k nnn..nn (e.g. Ok60Hz)
On
~XX100
0
Off
~XX100
1
Display message on the OSD
~XX210
nn…n (50 charactors)
Filter Wheel Index
~XX528
0000~9999
~XX530
1
O k 0000~9999
Phosphor Wheel Index
~XX529
0000~9999
~XX531
1
O k 0000~9999
Light Sensor Calibration
~XX552
1
Remote Control Simulation
Power
~XX140
1
Power Off
~XX140
2
Up
~XX140
10
Left
~XX140
11
Enter (for projection MENU)
~XX140
12
Right
~XX140
13
Down
~XX140
14
V Keystone +
~XX140
15
V Keystone -
~XX140
16
Brightness
~XX140
19
Menu
~XX140
20
VGA-1
~XX140
23
AV Mute
~XX140
24
Contrast
~XX140
28
Zoom +
~XX140
32
Zoom -
~XX140
33
Focus +
~XX140
34
Focus -
~XX140
35
Mode
~XX140
36
info
~XX140
40
Re-sync
~XX140
41
HDMI 1
~XX140
42
HDMI 2
~XX140
43
Source
~XX140
47
1
~XX140
51
2
~XX140
52
3
~XX140
53
4
~XX140
54
5
~XX140
55
6
~XX140
56
7
~XX140
57
8
~XX140
58
9
~XX140
59
0
~XX140
60
Source Lock
Information
Standby Power Mode
DHCP
Fan Speed
Note :
Some commands are not supported, it depends on models
11
-
Level 1
Level 2
Level 3
Level 4
Level 5
Level 6
n value
Read Command
Command
Command
Pass
CMD
CMD Value
CMD
Write Command
sp
ac
e
Set
Para.
Gamma
~XX140
61
PIP
~XX140
63
Lens H(left)
~XX140
64
Lens H(Right)
~XX140
65
Lens V(left)
~XX140
66
Lens V(Right)
~XX140
67
H Keystone +
~XX140
68
H Keystone -
~XX140
69
Hot Key (user1)(F1)
~XX140
70
Hot Key (user2)(F2)
~XX140
71
Pattern
~XX140
73
Exit
~XX140
74
Mute
~XX140
77
Return
~XX140
82
Note :
Some commands are not supported, it depends on models
12
-
Note *1
Power
Display Mode
~xx150
a
b
b
b
b
b
c
c
d
d
d
d
e
e
a=0 Power Off
Light Source Life = nnnn
cc=00 None
#
#
#
# ee=00 None
a=1 Power On
Calucalte by each mode formula
cc=01 DVI
ee=01 Presentation (Old: Cinema)
cc=02 VGA1
ee=02 Bright
cc=03 VGA2
ee=03 Cinema (Old: Movie/Photo)
cc=04 S-Video
ee=04 sRGB\Reference\Standard
cc=05 Video
ee=05 User(1)
cc=06 BNC
ee=06 User2
cc=07 HDMI1
ee=07 Blackboard
cc=08 HDMI2
ee=08 Classroom
cc=09 Wireless
ee=09 3D
cc=10 Compnent
ee=10 DICOM SIM.
cc=11 Flash drive
ee=11 Film
cc=12 Network Display(Presenter)
ee=12 Game
cc=13 USB Display
ee=13 Cinema
cc=14 HDMI3
ee=14 Vivid
cc=15 DisplayPort
ee=15 ISF Day
cc=16 HDBaseT
ee=16 ISF Night
cc=17 Multimedia
ee=17 ISF 3D
ee=18 2D high speed
ee=19 Blending Mode
ee=20 Sport
ee=21 HDR
ee=22 HDR SIM.
ee=23 Super Bright
ee=24 (Alexa auto check 2D/3D User)
Light Source Life
Input Source
Firmware Version
Note :
Some commands are not supported, it depends on models
