English 82
ADDITIONAL INFORMATION
Level 1 Level 2 Level 3 Level 4 Level 5 Level 6 n value
Read Command
Command Command
Pass CMD CMD Value CMD
Write Command
sp
ac
e Set
Para.
Green ~XX143 1
Magenta ~XX143 2
Red ~XX143 3
Cyan ~XX143 4
Black ~XX145 1
Transparent ~XX145 2
2x2 ~XX144 1
3x3 ~XX144 2
5x5 ~XX144 3
9x9 ~XX144 4
17x17 ~XX144 5
Off ~XX146 0
On ~XX146 1
Warp Sharpness 0 ~ 9 ~XX148 0~9
Blend Width
4 ~XX169 1
6 ~XX169 2
8 ~XX169 3
10 ~XX169 4
12 ~XX169 5
1.8 ~XX170 1
1.9 ~XX170 2
2.0 ~XX170 3
2.1 ~XX170 4
2.2 ~XX170 5
2.3 ~XX170 6
2.4 ~XX170 7
Bottom
Top
Off
~XX166 4/6
On ~XX166 3/5
Edit Area
Add Point
Remove Point
Brightness ~XX263 1/2/3/4
Red 0 ~ 255 ~XX281~XX285 nnn ~XX272~XX273 1 O k nnn
Green 0 ~ 255 ~XX282~XX286 nnn ~XX272~XX273 2 O k nnn
Blue 0 ~ 255 ~XX283~XX287 nnn ~XX272~XX273 3 O k nnn
Exit
Red 0 ~ 255
Green 0 ~ 255
Blue 0 ~ 255
Bottom
~XX167 3
Top ~XX167 5
All ~XX167 1
Save Memory Memory 1 ~ Memory 5 ~XX141 1~5
Apply Memory Memory 1 ~ Memory 5 ~XX147 1~5 ~XX137 1 O k 1~5
Clear Memory ~XX174 1
Reset ~XX561 1
Edge Mask 0 ~ 10 ~XX61 0~10
Unfreeze ~XX04 0
Freeze ~XX04 1
Off ~XX195 0
Green Grid ~XX195 3
Magenta Grid ~XX195 4
White Grid ~XX195 1
White ~XX195 2
Black ~XX195 11
Red ~XX195 5
Green ~XX195 6
Blue ~XX195 7
Yellow ~XX195 8
Magenta ~XX195 9
Cyan ~XX195 10
ANSI Contrast 4x4 ~XX195 14
Color bar ~XX195 13
Full screen ~XX195 15
Off ~XX302 0
PIP ~XX302 1
PBP ~XX302 2
[no Signal] ~XX121 1 O k 0
VGA ~XX12 5 ~XX121 1 O k 2
HDMI1 ~XX12 1 ~XX121 1 O k 7
HDMI2 ~XX12 15 ~XX121 1 O k 8
HDBaseT ~XX12 21 ~XX121 1 O k 16
[no Signal] ~XX131 1 O k 0
VGA ~XX305 2 ~XX131 1 O k 2
HDMI1 ~XX305 1 ~XX131 1 O k 7
HDMI2 ~XX305 4 ~XX131 1 O k 8
HDBaseT ~XX305 10 ~XX131 1 O k 16
Swap ~XX306 1
Display
Memory
Geometric Correction
Freeze Screen
Test Pattern
Main Source
Sub Source
PIP - PBP
Warp Inner
Warp Setting
Overlap Grid Number
Gamma
Blend Setting
Area
Enable
Brightness
Black Level
Reset
Screen
Grid Points
Grid Color
Advanced Warp
Grid Background
Note : Some commands are not supported, it depends on models 4 -
Note: Some commands are not supported, it depends on models .
