vMix Live Production Software Pro - Manual (Page 134)

vMix User Guide
134 / 208
One Channel HD Four Channel HD
Operating System Windows 7 or higher (64 bit only) Windows 7 or higher (64 bit only).
Windows 8.1 or higher
recommended
CPU Quad Core 3.4 Ghz Quad Core 4.0 Ghz (Six Core 3.6
Ghz highly recommended)
Memory 8GB 8GB
Graphics Card NVIDIA GeForce GTX 1050 or
higher NVIDIA GeForce GTX 1060 or
higher
Storage Dedicated SSD for Replay 200GB
and higher. Dedicated SSD for Replay 500GB
and higher. 1TB recommended.
Storage Connection Internal SATA or M.2 only Internal SATA 3 or faster only.
Camera Requirements
Instant Replay primarily works with cameras connected to a capture card.
This includes HDMI and SDI cameras connected to a capture card either via PCI Express, Thunderbolt or
USB 3.0.
NDI sources can also be used with Instant Replay as long as they are in the same format as the current
Replay Session.
Webcams, IP cameras, and other types of video sources are not directly supported.
To use these types of inputs, the "Output" camera option can be selected in the Instant Replay settings.
Output will capture everything that is currently playing to the output in vMix.
vMix Requirements
Note: Instant Replay and MultiCorder cannot be used at the same time.
Getting Started
To begin using vMix Replay, first add all of the cameras you will be using to vMix as inputs.
Next, click Add Input and select the Instant Replay tab as shown below:
Important: Click here to see the Instant Replay system requirements.
