Page 47
47
Appendices
Other Connectors
RS-232
D-sub 9-pin type
Tally/GPIO
Mini D-sub 15-pin type
USB 3.0 (device)
USB B type, USB-VIDEO (USB3.0), USB-AUDIO 2 IN/2 OUT (USB2.0), remote control from PC
Display
Graphic Color LCD, 320 x 240 dots, touch panel
Other Functions
MEMORY (8 types), FREEZE (input video captured), OUTPUT FADE (Audio, Video: WHITE or BLACK), INPUT CAPTURE
Other
Power Supply
AC Adaptor
Current Draw
3 A
Power Consumption
36 W
Operation Temperature
+0 to +40 degrees Celsius
+32 to +104 degrees Fahrenheit
Dimensions
339 (W) x 217 (D) x 87 (H) mm
13-3/8 (W) x 8-9/16 (D) x 3-7/16 (H) inches
Weight
(excluding AC adaptor)
2.4 kg
5 lbs 5 oz
Accessories
Owner’s manual, AC adaptor, Power cord
* 0 dBu=0.775 Vrms
* This document explains the specifications of the product at the time that the document was issued. For the latest information, refer to the Roland website.
Dimensions
339
87
70
217
210
215
7
Unit: mm
