Function description
Operating Manual PSSu E S INC 24V se(T)
1001380EN03
12
4
Function description
4.1
Module features
4.1.1
Integrated protection mechanisms
When the PSSu E F PS1(T) is used to supply the system, the module supply is buffered
for 20 ms if the supply voltage is interrupted.
The module detects the following errors:
}
Startup error
}
Configuration error
}
ST communication error
}
Bus termination error
}
Supply voltage overload for the encoder
4.1.2
Function description
Module supply
}
The module supply provides the module with voltage.
Inputs
}
3 singlepole inputs referenced to earth: A, B, C, for connecting an incremental encoder
or an encoder that provides rising edges as counter pulses.
}
3 singlepole inputs referenced to earth: G, L, S, for special functions
Outputs:
}
Supply voltage for encoder, 24 VDC, 100 mA
}
Semiconductor output (switches depending on the counter status)
“0” signal (0 V) at the output:
}
Output is high impedance
–
No current to the load
“1” signal (+24 V) at the output:
}
Output is low impedance
–
Current is supplied to the load
Operating modes
}
Incremental encoder
}
Counter
Functions
}
Period length measurement
or
}
Storing the counter status in latch memory after a latch pulse or zero pulse
}
Setting the counter status
