Technical details
Operating Manual PSSu E S INC 24V se(­T)
1001380­EN­03 39
Incremental encoder input 312486 314486
Typ. input current of the LATCH
and/or GATE and/or STATUS sig­
nals at high level
4,0 mA 4,0 mA
Max. number of bits on the counter
input
32 Bit 32 Bit
Evaluation of counter pulses 1x, 2x, 4x 1x, 2x, 4x
Phase offset between differential
signals A and B
90 deg 90 deg
Phase offset tolerance 30 deg 30 deg
Maximum cutoff frequency 0,2 MHz 0,2 MHz
Time constant of input filter on
LATCH signal
50 µs 50 µs
Time constant of input filter on
GATE signal
50 µs 50 µs
Time constant of input filter on
STATUS signal
50 µs 50 µs
Typ. processing time 0,1 ms 0,1 ms
Potential isolation between input/
output and periphery supply
No No
Potential isolation between input/
output and voltage for the internal
module bus
Yes Yes
Semiconductor outputs 312486 314486
Voltage 24 V DC 24 V DC
Max. output current at rated
voltage
0,50 A 0,50 A
Max. output current at rated
voltage
0,10 A 0,10 A
Environmental data 312486 314486
Climatic suitability EN 60068­2­1, EN 60068­2­14, EN
60068­2­2, EN 60068­2­30, EN
60068­2­78 EN 60068­2­1, EN 60068­2­14, EN
60068­2­2, EN 60068­2­30, EN
60068­2­78
Ambient temperature
In accordance with the standard EN 60068­2­14 EN 60068­2­14
Temperature range 0 ­ 60 °C ­40 ­ 70 °C
Storage temperature
In accordance with the standard EN 60068­2­1/­2 EN 60068­2­1/­2
Temperature range ­25 ­ 70 °C ­40 ­ 70 °C
Climatic suitability
In accordance with the standard EN 60068­2­30, EN 60068­2­78 EN 60068­2­30, EN 60068­2­78
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C
Condensation during operation Not permitted Short­term
EMC EN 61000­4­2, EN 61000­4­3, EN
61000­4­4, EN 61000­4­5, EN
61000­4­6, EN 61000­6­2, EN
61000­6­4 EN 61000­4­2, EN 61000­4­3, EN
61000­4­4, EN 61000­4­5, EN
61000­4­6, EN 61000­6­2, EN
61000­6­4
