Wiring
Operating Manual PSSu E S INC 24V se(­T)
1001380­EN­03 34
6.3 Connecting the module
Incremental encoder
operating mode
With C­rail
Encoder is supplied
via output 14 (S1)
Output O0: Output for
limit value monitoring
21 11
22 12
23 13
24 14
41 31
42 32
43 33
44 34
Gate
C
Status
B
A
Latch
0 V
24 V
Output O0
Incremental encoder
operating mode
Without C­rail
Encoder is supplied
via output 14 (S1)
Output O0: Output for
limit value monitoring
21 11
22 12
23 13
24 14
41 31
42 32
43 33
44 34
Gate
C
Status
B
A
Latch
0 V
24 V
Output O0
