Technical details
Operating Manual PSSu E S INC 24V se(­T)
1001380­EN­03 38
8 Technical details
General 312486 314486
Approvals BG, CE, GOST, TÜV, cULus Lis­
ted
CE, cULus Listed
Application range Standard Standard
Module's device code 0322h 0322h
Number of ST input bits 64 64
Number of ST output bits 64 64
Number of ST status bits 8 8
Number of ST control bits 8 8
Application in system environment
A
From ST firmware version, other
head modules
18 18
From ST firmware version PSSu
H S PN
3 3
Application in system environment
B
From ST firmware version, head
modules
1.7.0 1.7.0
Electrical data 312486 314486
Internal supply voltage (module
supply)
Supply voltage range of module
supply
4,8 ­ 5,4 V 4,8 ­ 5,4 V
Module's current consumption 170 mA 170 mA
Module's power consumption 0,85 W 0,85 W
Periphery's supply voltage (peri­
phery supply)
Voltage range 16,8 ­ 30,0 V 16,8 ­ 30,0 V
Module's current consumption
with no load
10 mA 10 mA
Module's power consumption
with no load
0,24 W 0,24 W
Max. power dissipation of module 1,40 W 1,40 W
Incremental encoder input 312486 314486
Number of counter inputs 1 1
Type of counter inputs Incremental encoder Incremental encoder
Signal at counter inputs A and B
and/or C
single­ended (HTL) single­ended (HTL)
Permitted low signal range on
LATCH/GATE/STATUS signals
­3 ­ 5 V ­3 ­ 5 V
Permitted high signal range on
LATCH/GATE/STATUS signals
11 ­ 30 V 11 ­ 30 V
Typ. input current of the LATCH
and/or GATE and/or STATUS sig­
nals at low level
0 mA 0 mA
