Function description
Operating Manual PSSu E S INC 24V se(­T)
1001380­EN­03 22
Description
ST­PII bit assign­
ment LSB … MSB ST­PIO bit assign­
ment LSB … MSB
Notes
Status byte 0 … 7 See "Status byte as­
signment" table
Current counter
status 8 … 39 Measured value in
incremental encoder
or counter operating
mode
Counter status from
the latch memory or
result from the period
length measurement 40 … 71 Value recorded after
a latch or zero pulse
or period length
Byte for function calls 0 … 7 See table: "Overview
of function calls"
Default counter
status 8 … 39 Value at which the
counter is set
Specify limit value 40 … 71 Value at which the
limit value is set
Overview of function calls:
Function calls Bit Assignment
Transfer counter status via
zero pulse 0 0: Input C (zero pulse) inactive
1: Input C (zero pulse) active
Transfer counter status via
latch pulse or measure
period length
(1)
1 0: Input L (latch pulse) inactive/period length meas­
urement inactive
1: Input L (latch pulse) active/period length meas­
urement active
Set counter status 2 0: Do not transfer default counter status
1: Adopt default counter status
Monitor limit value 3 0: Limit value monitoring inactive
1: Limit value monitoring active
Invert output O0 4 0: Output O0 not inverted
1: Output O0 inverted
5 … 7 Reserved
(1) Whether the period length is measured or the latch pulse is evaluated, must be defined in
the PSSu Configurator.
