Technical details
Operating Manual PSSu E S INC 24V se(­T)
1001380­EN­03 40
Environmental data 312486 314486
Vibration
In accordance with the standard EN 60068­2­6 EN 60068­2­6
Frequency 10,0 ­ 150,0 Hz 10,0 ­ 1000,0 Hz
Amplitude 0,35 mm 0,35 mm
Acceleration 1g 5g
Broadband noise
In accordance with the standard – EN 60068­2­64
Frequency – 5 ­ 500 Hz
Acceleration – 1,9grms
Shock stress
In accordance with the standard EN 60068­2­27 EN 60068­2­27
Acceleration 15g 15g
Duration 11 ms 11 ms
In accordance with the standard EN 60068­2­29 EN 60068­2­29
Acceleration 10g 25g
Duration 16 ms 6 ms
Max. operating height above sea
level
2000 m 5000 m
Airgap creepage
In accordance with the standard EN 60664­1 EN 60664­1
Overvoltage category II II
Pollution degree 2 2
Protection type
In accordance with the standard EN 60529 EN 60529
Mounting area (e.g. control cab­
inet)
IP54 IP54
Housing IP20 IP20
Terminals IP20 IP20
Mechanical data 312486 314486
Material
Bottom PC PC
Front PC PC
Coding PA PA
Mounting type plug­in plug­in
Dimensions
Height 76,0 mm 76,0 mm
Width 25,2 mm 25,2 mm
Depth 60,2 mm 60,2 mm
Weight 47 g 48 g
Mechanical coding
Type M M
Colour Dark grey Dark grey
The standards current on 2005­04 apply.
