Function description
Operating Manual PSSu E S INC 24V se(­T)
1001380­EN­03 24
4.2.2.2 PSSu assignment in system environment B
Data access is via pre­defined I/O data types:
I/O data
name
I/O data type I/O data element Meaning
OutputData ST_O_INC_24
V ZeroPulseActiv:
BOOL FALSE: Input C (zero pulse) inact­
ive
TRUE: Input C (zero pulse) active
LatchOrMeasure:
BOOL FALSE: Input L (latch pulse) inact­
ive/period length measurement in­
active
TRUE: Input L (latch pulse) active/
period length measurement active
SetCounter: BOOL FALSE: Do not transfer default
counter status
TRUE: Adopt default counter status
NewCounterValue:
DWORD Default counter status
LimitValueActive:
BOOL FALSE: Limit value monitoring in­
active
TRUE: Limit value monitoring act­
ive
InvertOutput: BOOL FALSE: Output O0 not inverted
TRUE: Output O0 inverted
LimitValue: DWORD Value at which the limit value is set
