Function description
Operating Manual PSSu E S INC 24V se(­T)
1001380­EN­03 23
Status byte assignment:
Meaning Bit Assignment
Zero pulse 0 0: No zero pulse at input C
1: Zero pulse at input C
Latch pulse or period length
measurement 1 0: Period length or contents of latch memory not
transferred
1: Period length or contents of latch memory trans­
ferred
Default counter status 2 0: Default counter status not transferred
1: Default counter status transferred
Counter underflow 3 0: No counter underflow
1: Counter underflow
Counter overflow 4 0: No counter overflow
1: Counter overflow
Status input S, Bit 1 5 0: Status input, Bit 1 (message from encoder)
1: Status input, Bit 1
Status input S, Bit 2 6 0: Status input, Bit 2 (1)
1: Status input, Bit 2
Reserved 7 ­
(1) When configuring the module, users can determine the evaluation method for the status
input: single, redundant or diverse. Transmitting the status via two bits enables simple fault
detection: Two redundant bits must always be the same, two diverse bits must always be
different, otherwise the transmission is faulty.
