IP Core Configuration
Slave Controller – IP Core for Xilinx FPGAs III-37
SyncManager Event Times
Distributed Clocks SyncManager Event Times (0x09F0:0x09FF) are available if checked. Used for
debugging SyncManager interactions.
EPU and PDI Error Counter
EtherCAT Processing Unit (EPU) and PDI Error counters (0x030C:0x030D) are available if checked.
Lost Link Counter
Lost Link Counters (0x0310:0x0313) are available if checked.
EEPROM Emulation by PDI
EEPROM is and has to be emulated by a µController with access to a NVRAM. I²C EEPROM is not
necessary if EEPROM Emulation is activated, I²C interface is deactivated. Only usable with PDIs for
µController connection.
RESET slave by ECAT/PDI
The reset registers (0x0040:0x0041) and the RESET_OUT signal is available if this feature is
checked.
RUN LED (Dev_State)
RUN LED output (DEV_STATE) indicates AL Status (0x0130) if activated. Otherwise RUN LED has to
be controlled by a µController. Always activated if no PDI is selected or if Digital I/O PDI is selected.
Extended RUN/ERR LED
Support for ERR LED and STATE LED, direct control of RUN/ERR LED via RUN/ERR LED Override
register (0x0138:0x0139).
