Basic Operation 13
2.5 Standard Keys
Start
<START> is used to start the main clock.
Stop
<STOP> is used to stop the main clock.
Enter/Edit
The <ENTER*/EDIT> key has dual functions. The key functions as the enter key when
editing game data. Pressing the key will accept the new data and exit the edit mode. If not in
Edit mode, the key allows the user to select the item to be edited, such as team score. After
pressing the <ENTER*/EDIT> key, the operator then presses one of the increment or
decrement keys for the desired field on the scoreboard. The operator then enters the new
value to display and presses <ENTER*/EDIT> to accept.
Clear/Alt
The <CLEAR/ALT> key has two functions. The key operates as the clear key when editing
game data. Pressing the key will clear the data being edited, or, if pressed twice, will exit the
edit mode. When not in Edit mode the <CLEAR/ALT> key allows the user to access the
alternate function keys. Pressing the <CLEAR/ALT> and one of the alternate function keys
will initiate the desired function.
Set Time
Display Action
MM:SS.T = minutes, seconds,
tenths of a second
After the main clock has been stopped, press <SET TIME  >
to display the current time of the main clock.
To change the time, enter the desired value on the number pad
and press <ENTER*/EDIT>.
Press <CLEAR/ALT> twice to cancel any changes and return
to the game.
Count Up/Down
Display Action
After the main clock has been stopped, the direction of the
clock can be set using the <COUNT UP/DN> function.
Press <1> or <2> to select UP or DOWN (default).
Note: The current direction of the main clock is shown on
the top line of the LCD.
MAI N CLOCK-SET
CURR MM:SS.T*
MAI N CLOCK-DOWN
1-UP, 2-DOWN
