32 Baseball Operation
Display Action
Press the <HIT> or <ERROR> key to turn on the Hit or Error
indicator or digits.
This display appears briefly.
Home/Guest Score +1, -1
The <HOME SCORE +1> and <HOME SCORE -1> and <GUEST SCORE +1> and <GUEST
SCORE -1> keys are used to increment or decrement their respective totals.
Display Action
NN = current setting
Press the appropriate home or guest <SCORE +1> or
<SCORE -1> key to increment or decrement the total number
of runs for the team.
The <ENTER*/EDIT> key permits the user to select and edit
Runs +1 or
–1. First, press <ENTER*/EDIT> and the key for
the home or guest field to be edited, then enter the correct
number and press <ENTER*/EDIT>.
Time, At Bat, P-Count, H/E (Alternative Key)
The <TIME>, <AT BAT>, <P-COUNT>, and <H/E> keys are used to select what is shown on
the two time digits. First press the <CLEAR/ALT> key and then one of the above keys to
select what is displayed on the two time digits. If <TIME> is selected, they will show two
digits of time. If <AT BAT> is selected, they will show the player At Bat. If <P-COUNT> is
selected they will show the pitch count of the current pitcher. If <H/E> is selected, they will
show an „H‟ or an „E‟ on the first digit when <HIT> or <ERROR> is pressed.
Pitch (Alternative Key)
The Home and Guest <PITCH> keys will edit the Home and Guest pitch count.
Display Action
NNN = current setting
Press the <CLEAR/ALT> key and then press one of the pitch
keys. Enter the pitch count and then press <ENTER*/EDIT>.
Time/At Bat
The <TIME/AT BAT  > key operates as the standard SET TIME key if the console is set to
show the time. If the console is set to show AT BAT it will operate as shown below.
Display Action
NN = current setting
Press the <TIME/AT BAT > key, enter the current batter
number and press <ENTER*/EDIT>.
ERROR: ON
TEAM SCORE: +1
HOME NN
PI TCHES EDI T
HOME NNN*
AT BAT: EDI T
NN*
