Squash Operation 43
Section 14: Squash Operation
Sport Insert: 0G-199192 (Code 16)
The sport insert drawings are located in Appendix B. The block diagram drawings are located in
Appendix A.
Reference Drawings:
Insert; 0G-199192; A/S 1600 Squash ................................................................. Drawing A-199192
System Riser Diagram; Indoor/Outdoor A/S 1600 .............................................. Drawing A-139544
Refer to the information in Section 2 to start up the console and use the sport insert.
If an insert is lost or damaged, a copy of the insert drawing can be used until a replacement arrives.
If the code number for a scoreboard is unknown, refer to Appendix C. If the model number of a
scoreboard is unknown, refer to the documentation provided with the scoreboard.
14.1 Squash Keys
Home/Guest Game Score +1, -1
The <GAME SCORE +1> and <GAME SCORE -1> keys are used to increment or decrement
the home or guest game score.
Display Action
Press the appropriate key to increment the game score for the
home or guest team.
The LCD shows home and guest scores and the games won.
Press <ENTER*/EDIT> then either of the Game score keys to
display the current setting. Enter the correct number and press
<ENTER*/EDIT>.
Reset Game Score
Press <RESET GAME SCORE> to reset both home and guest scores to zero. This key is used
to clear the Game Score fields at the beginning of each game.
H=6 M23 G=4
3 GAMES WON 1
