Volleyball Operation 29
Section 8: Volleyball Operation
Sport Insert: LL-2502 (Code 02) (Code 82)
The sport insert drawings are located in Appendix B. The block diagram drawings are located in
Appendix A.
Reference Drawings:
Insert; LL-2502 A/S 1600, Volleyball ................................................................... Drawing A-139482
System Riser Diagram; Indoor/Outdoor A/S 1600 .............................................. Drawing A-139544
Refer to the information in Section 2 to start up the console and use the sport insert.
If an insert is lost or damaged, a copy of the insert drawing can be used until a replacement arrives.
If the code number for a scoreboard is unknown, refer to Appendix C. If the model number of a
scoreboard is unknown, refer to the documentation provided with the scoreboard.
8.1 Volleyball Keys
Game +1, -1
The <GAME +1> and <GAME -1> keys are used to increment or decrement and team totals.
Display Action
N = current setting
Press the appropriate key to increment statistics for the home
or guest team. The LCD shows which key was pressed and
the new value.
Press <ENTER*/EDIT> and either of the Game keys to
display the current setting. Enter the correct number and
press <ENTER*/EDIT>.
Reset Game Score
Press <RESET GAME SCORE> to reset both home and guest scores to zero. This key is used
to clear the Game Score fields at the beginning of each match.
Home/Guest Won +1, -1
The <HOME WON +1> and <HOME WON -1> and <GUEST WON +1> and <GUEST
WON -1> keys are used to increment or decrement their respective totals.
Display Action
NN = current setting
Press the home or guest <WON +1> key to increment the
number of games won by the team. Press the home or guest
<WON -1> key to decrement the number of games won.
Press <ENTER*/EDIT> then either of the home or guest
<WON +1> keys to display the current setting. Enter the
correct number and press <ENTER*/EDIT>.
GAME NO: +1
N
GAMES WON: +1
HOME NN
