Field Events Operation 37
Section 11: Field Events Operation
Sport Insert: 0G-140229:
Metric 1: Discus, Hammer Javelin (Code 11)
Metric 2: Long/Triple Jump, Shot Put (Code 12)
Metric 3: High Jump, Pole Vault (Code 13)
Imperial (Code 14)
The sport insert drawings are located in Appendix B. The block diagram drawings are located in
Appendix A.
Reference Drawings:
Insert, 0G-140229; A/S 1600 Field Event Board ................................................ Drawing A-140229
System Riser Diagram; Indoor/Outdoor A/S1600 ............................................... Drawing A-139544
Refer to the information in Section 2 to start up the console and use the sport insert.
If an insert is lost or damaged, a copy of the insert drawing can be used until a replacement arrives.
If the code number for a scoreboard is unknown, refer to Appendix C. If the model number of a
scoreboard is unknown, refer to the documentation provided with the scoreboard.
11.1 Field Events Keys
Competitor
The <COMPETITOR > key is used to enter the competitor number.
Display Action
NNN = current setting
Press the <COMPETITOR > key to display the current
competitor number.
Enter the desired number and press <ENTER*/EDIT>.
Attempt
The <ATTEMPT> key is used to enter the attempt number.
Display Action
N = current setting
Press the <ATTEMPT > key to display the current attempt
number.
Enter the desired number and press <ENTER*/EDIT>.
COMPETI TOR
NNN*
ATTEMPT
N*
