Multipurpose Timer 19
Section 4: Multipurpose Timer
Sport Insert: LL-2499 (Code 07)
The sport insert drawing is located in Appendix B. The block diagram drawings are located in
Appendix A.
Reference Drawings:
Insert; LL-2499 A/S 1600, Multipurpose Timer ................................................... Drawing A-139487
System Riser Diagram, Indoor/Outdoor A/S 1600 .............................................. Drawing A-139544
Refer Section 2 for information on starting the console and for instructions for use of the sport insert.
If an insert is lost or damaged, a copy of the insert drawing can be used until a replacement arrives.
If the code number for a scoreboard is unknown, refer to Appendix C. If the model number of a
scoreboard is unknown, refer to the documentation provided with the scoreboard.
4.1 General Multipurpose Timer Information
The sport insert for the timer is LL-2499, and Code 07 is used to run the timer. The
multipurpose timer is a general timer used for two-, four-, and six-digit time displays.
The timer counts up or down through hours, minutes and seconds. The information shifts on
the two- and four-digit displays to show the most significant time values as the time changes.
TOD/Game
The <TOD/GAME > key toggles the console between displaying game time or time of day
(TOD), allowing the user to change the time of day.
Press <TOD/GAME  > to display the Time of Day prompt if the console is currently
showing Game Time. If Time of Day is currently displayed, it will change to Game Time.
Display Action
HH:MM:SS = hours, minutes,
seconds
Enter the time of day in hours, minutes, and seconds and
press <ENTER*/EDIT>.
The time of day clock is now displayed on the console.
EDI T TOD
HH:MM:SS*
