Basketball Operation 45
Section 15: Basketball Operation
Sport Insert: LL-2667 (Code 21) (Code 88)
The sport insert drawings are located in Appendix B. The block diagram drawings are located in
Appendix A.
Reference Drawings:
Insert: LL-2667- A/S Basketball- Code 21 .......................................................... Drawing A-303302
System Riser Diagram; Indoor/Outdoor A/S 1600 .............................................. Drawing A-139544
Refer to the information in Section 2 to start up the console and use the sport insert.
If an insert is lost or damaged, a copy of the insert drawing can be used until a replacement arrives.
If the code number for a scoreboard is unknown, refer to Appendix C. If the model number of a
scoreboard is unknown, refer to the documentation provided with the scoreboard.
15.1 Basketball Keys
Home/Guest Game Score +1, +2, +3, -1
The Home Score +1,+2,+3 and Home Score -1 and Guest Score +1,+2,+3 and Guest Score -1
keys are used to increment or decrement their respective totals.
Display Action
NNN = current setting
Press home or guest <SCORE +1, +2, +3> or <SCORE -1> to
increment or decrement the total number of points for the
team. The LCD shows which key was pressed and the new
value for the corresponding team.
The +3 and -1 keys are alternate keys and require
<CLEAR/ALT> to be pressed first.
Press <ENTER*/EDIT> and the key for the home or guest field
to be edited. Then enter the correct number and press
<ENTER*/EDIT>.
Period +1
Display Action
N = current setting
Press <PERIOD + 1> to increment the current period.
The LCD shows which key was pressed and the new value.
To edit the period, press <ENTER*/EDIT> then <PERIOD +
1>. Enter the desired number and press <ENTER*/EDIT>.
TEAM SCORE:+1
HOME NNN
PERI OD +1
N
