Gymnastics Operation 41
Section 13: Gymnastics Operation
Sport Insert: 0G-144810 (Code 15)
The sport insert drawings are located in Appendix B. The block diagram drawings are located in
Appendix A.
Reference Drawings:
Insert; A/S 1600 Gymnastics .............................................................................. Drawing A-144810
System Riser Diagram; Indoor/Outdoor A/S 1600 .............................................. Drawing A-139544
Refer to the information in Section 2 to start up the console and use the sport insert.
If an insert is lost or damaged, a copy of the insert drawing can be used until a replacement arrives.
If the code number for a scoreboard is unknown, refer to Appendix C. If the model number of a
scoreboard is unknown, refer to the documentation provided with the scoreboard.
13.1 Gymnastics
Competitor
The < COMPETITOR > key is used to enter the competitor number.
Display Action
NNN = current setting
Press the <COMPETITOR > key to display the current
competitor number.
Enter the desired number and press <ENTER*/EDIT>.
Score
Display Action
NNN = current setting
Press the <SCORE > key to display the score for the current
competitor.
Enter the score value and press <ENTER*/EDIT>.
Blank Display
Press the <BLANK DISPLAY> key to blank the competitor number and score information.
This key will blank the information on the scoreboard and in the console.
SCORE
NNN*
COMPETI TOR
NNN*
