Tennis Operation 33
Section 10: Tennis Operation
Sport Insert: LL-2497 (Code 08)
The sport insert drawings are located in Appendix B. The block diagram drawings are located in
Appendix A.
Reference Drawings:
Insert; LL-2497 A/S 1600, Tennis ....................................................................... Drawing A-139494
System Riser Diagram; Indoor/Outdoor A/S 1600 .............................................. Drawing A-139544
Refer to the information in Section 2 to start up the console and use the sport insert.
If an insert is lost or damaged, a copy of the insert drawing can be used until a replacement arrives.
If the code number for a scoreboard is unknown, refer to Appendix C. If the model number of a
scoreboard is unknown, refer to the documentation provided with the scoreboard.
10.1 Tennis Keys
TOD/Game
The <TOD/GAME > key toggles the console between displaying Game Time or Time of
Day (TOD). It also allows the user to change the time of day.
Press <TOD/GAME  > to display the Time of Day prompt if the console is currently
showing Game Time. If Time of Day is currently displayed, it will change to Game Time.
Display Action
HH:MM:SS = hours, minutes,
seconds
Enter the time of day in hours, minutes, and seconds and
press <ENTER*/EDIT>.
The time of day clock is now displayed on the console.
Serve
Display Action
<SERVE> turns the serve indicators on or off for the
respective player.
EDI T TOD
HH:MM:SS*
TOP SERVE
ON
