Segment Timer 21
Section 5: Segment Timer
Sport Insert: LL-2498 (Code 06)
The sport insert drawings are located in Appendix B. The block diagram drawings are located in
Appendix A.
Reference Drawings:
Insert; LL-2498 A/S 1600, Segment Timer ......................................................... Drawing A-139492
Refer to the information in Section 2 to start up the console and use the sport insert.
If an insert is lost or damaged, a copy of the insert drawing can be used until a replacement arrives.
If the code number for a scoreboard is unknown, refer to Appendix C. If the model number of a
scoreboard is unknown, refer to the documentation provided with the scoreboard.
5.1 Accessing Segment Timer
To run the segment timer for the dedicated segment timer display, enter Code 06 at the Enter
Code command.
5.2 Segment Timer Information
The segment timer is used to time events such as practice sessions. The operation of the
segment timer is determined by 40 segments of pre-programmed length. The segment timer
will count down starting at the segment number that is set as First Segment. When the first
segment is completed, the segment timer will count the Interval Time and proceed with the
next segment. The timer will continue counting segments until the segment number that is
set as Last Segment is counted down. It then will reset to the segment saved as the First
Segment and will either begin counting down or pause for the <START> key to be pressed,
depending on the Auto Stop At Last Seg setting. To stop the timer after each segment is
completed, use the Auto Stop feature.
The First Segment and Last Segment values can be used to set up specific practice sessions.
For example, the practice session for one sport could be programmed to use segments 1-10,
while another might use segments 11-20. Set the First Segment and Last Segment values to
the desired segment numbers for the session, and the console will count down each of the
segments in order, either stopping on the last segment or looping through included segments
again, based on the Auto Stop At Last Seg setting.
The default First Segment value is 1. The default value for the Last Segment is 40.
