Shot/Play Clock & Pitch Timer Operation 27
Section 7: Shot/Play Clock & Pitch Timer
Operation
Sport Insert: LL-2501
Shot Clock (Code 04) (Code 84)
Play Clock/Pitch Timer (Code 05) (Code 85)
The sport insert drawings are located in Appendix B. The block diagram drawings are located in
Appendix A.
Reference Drawings:
Insert; LL-2501 A/S 1600, Shot/Play Clock......................................................... Drawing A-139889
System Layout - Independent Shot Clock System ............................................. Drawing A-139547
Refer to the information in Section 2 to start up the console and use the sport insert.
If an insert is lost or damaged, a copy of the insert drawing can be used until a replacement arrives.
If the code number for a scoreboard is unknown, refer to Appendix C. If the model number of a
scoreboard is unknown, refer to the documentation provided with the scoreboard.
7.1 Shot/Play Clock & Pitch Timer Keys
Set Time, Set Reset 1, Set Reset 2
Display Action
Note: The example shows operation in Play Clock mode.
<SET RESET 1 > sets the current Reset 1 value for the shot
clock, play clock, or pitch timer.
<SET RESET 2 > sets the current Reset 2 value for the shot
clock, play clock, or pitch timer.
<SET TIME > sets the current time for the shot clock, play
clock, or pitch timer.
Reset on Stop (Play Clock mode only)
After editing the RESET 1 time, the console will ask whether or
not to reset the time after pressing <STOP>.
Typically, YES will only be selected when using remote
start/stop sideline kits that have just one RESET button.
PLAY CLOCK
RESET 1 - MM:SS*
PLAY CLOCK
RESET 2 - MM:SS*
PLAY CLOCK EDI T
CURR - MM:SS*
RESET ON STOP?
1-YES 2-NO
