04 —Read Input Registers
Reads the binary contents of the input registers in the field units. This function code will map the
following field unit registers 4 – 8 into a data table.
Read Input Registers Data Table
Master
Field Unit
Field Unit
Station Register
Register
Address
MX-DDC
UEC-3-DDC
30001
4
1
Torque Scaled Output*
Average Torque Output
30002
5
1
Main Volts
Analog Input
30003
6
1
Analog Input
Analog Input
30004
7
1
Analog Input
Analog Input
30005
8
1
Valve Position (Scaled)
Valve Position (Scaled)
30006
4
2
Torque Scaled Output*
Average Torque Output
30007
5
2
Main Volts
Analog Input
30008
6
2
Analog Input
Analog Input
30009
7
2
Analog Input
Analog Input
30010
8
2
Valve Position (Scaled)
Valve Position (Scaled)
