Figure 16-5: HMI Lockout Alert
If HMI control has been set to “Off”, this screen appears when the user attempts control from the Master Station touch
screen while the DCS is communicating with the Master Station.
Figure 16-6: HMI Control Verification screen
If HMI Control is turned OFF, the user will see an error screen if control is attempted while DCS or MNET traffic is
present.
HMI Control Verification
This unit is configured for
"HMI Control Disabled" during
DCS or MNET communications traffic.
Please wait while DCS and MNET
communications traffic is monitored.
OK
This operation cannot be
performed at this time,
since there is communication
traffic on the DCS port or
the MNET port.
Please try again.
Alert
