System Snapshots Button
Click the S YSTEM S NAPSHOTS button to display the Confirm System Snapshot window shown in Figure
25.
Figure 24. System Snapshots button
The S YSTEM S NAPSHOTS button allows a user to download or to view system snapshots saved to the
local computer. Only users with permission to download configurations can take a snapshot of the
current system.
System Snapshots
A System Snapshot contains the available status at a specific point in time. Additionally, the snapshot
includes two log files: the Admin Log and the Sys Log.
Admin Log – The Admin Log contains all information pertaining to user interaction with the system.
Sys Log – The Sys Log contains operating system messages.
Figure 25. Confirm System Snapshot screen
Download Snapshot – clicking on D OWNLOAD S NAPSHOT provides a listing of logged events at a
specific point in time as a documentation or troubleshooting tool. It can be saved to the local computer
for future reference.
View Snapshot – clicking on V IEW S NAPSHOT displays an existing Snapshot stored on the local
computer.
