4-30 MAX200 Service Manual
15
PARTS LIST
Recommended Spare Parts
Power Supply
Part
Number
Description Designator
005041 Switch, tog 2pl Maint ON/ON S1
005121 Pushbutton, green, illmn. PB1
005122 Pushbutton, red, extended PB2
005151 Holder, lamp -
005168 Bulb, 28 VDC -
005091 Lens, white -
009604 Resistor, variable, 100 K, 1 turn R9
027080 Fan, 225 CFM, 120 VAC, 50/60 Hz M2
027079 Fan, 450-550 CFM, 120 VAC, 50/60 Hz M4
027080 Fan, 225 CFM, 120 VAC, 50/60 Hz M3
*041151 PCB, THC motherboard PCB9
*041186 PCB, SA-THC PCB10
041143 PCB, Control PCB7
005102 Thermostat, 160°C, 6 Amp TS1
006014 Valve, solenoid V1
005093 Switch, pressure, 0-90 psi PS1
129118 CH130 Chopper SA CE/LVD CH1/CH2
041534 PCB, power distribution PCB6
**008551 Fuse, 7.5 Amp, 600VAC F1, F2
***008709 Fuse, 20 Amp, 500VAC F1, F2
008317 Fuse, semiconductor, 125 Amp, 250 V F3, F4
003021 Relay, 120 VAC CR1
005130 Switch, pressure, SPDT, 0-15 psi PS3
029317 Transformer, High Voltage SA T5
029202 Sensor, current CS1
027005 Filter, coolant -
011025 Filter/regulator FR1
011031 Filter Element (used with 011025) -
011027 Gauge, high pressure -
128384 Kit: coolant Pump with clamp -
029323 Switch, water temperature, 162°F TS2
029326 Switch, level LS1
029361 Switch, flow, 0.5 gpm FS1
006053 Valve, check 1/3 psi, 1/4 NPTH
028872 Coolant, propylene glycol 30%/
deionized water 70% (standard mixture)
028873 Coolant, propylene glycol 100%
* Power Supplies with THC
** Used when incoming power is 380V, 415V, 400V or 480V
*** Used when incoming power is 208V, 220V, or 240V
