2BHardware Connections

3.2.2 Connections to Equipment with 25-Pin AES/EBU D-Sub Connectors

The CBL-AES1603 and CBL-AES1605 breakout cables are provide 25-pin D-sub connections for industry standard
equipment. Refer to the table in Section 3.2 AES/EBU Cable Connections for equipment compatibility information.

Connect the 26-pin high-density connecter on each cable to I/O Ports A and B. Connect the 25-pin D-sub connector
on each cable to the external device. Tighten the thumbscrews on the cable shells for a secure connection.

The signals associated with each 25-pin D-sub connector depend on which I/O Port on is used according to the
following table:

Lynx Cable

Port Connected To

Signals on 25-Pin D-sub

CBL-AES1603

I/O Port A

DIGITAL IN 1-8

CBL-AES1603

I/O Port B

DIGITAL OUT 1-8

CBL-AES1605

I/O Port A

DIGITAL IN 1-4 and

DIGITAL OUT 1-4

CBL-AES1605

I/O Port B

DIGITAL IN 5-8 and

DIGITAL 5-8

3.3 Clock Connections

In any system with more than one digital device, there can be only one master clock providing synchronization.
Whether you designate the AES16 as the clock master (slaving all other devices to it) or slave the AES16 to another
clock master, it is important that only a single device act as clock master, to prevent the occurrence of audible digital
errors.

The AES16 provides connections that allow for synchronization with external equipment or internal devices within
the computer.

3.3.1 External Clocking

Clock connections to external equipment are currently provided only with the CBL-AES1604 XLR breakout cable.
However, the AES16 can still be synchronized to external equipment using its AES/EBU digital I/O.

With the CBL-AES1604 Cable connected to I/O Port A of the AES16, the BNC connector labeled CLOCK acts a
clock input. This input supports TTL signal levels and is terminated with 75 ohms of impedance.

Connect this input to the clock output of an external device and select “External” as the Sample Clock Source in the
Lynx Mixer. Adjust the Sample Clock Reference to match the incoming clock type.

With the CBL-AES1604 Cable connected to I/O Port B of the AES16, the BNC connector labeled CLOCK acts a
word clock output. This output provides a 75-ohm TTL level signal at a frequency that tracks the sample clock rate
of the AES16. Connect this output to the word clock input of an external device.
