A-4 Supplement / HopNet Modems 887997 LogBook User’s Manual, Appendix A
Testing the LogBook and Modem Connectivity
In this section, steps are provided to:
• Verify the Parallel Port connectivity.
• Configure the LogBook’s Serial Connections. This configuration is done via Parallel Port
• Verify that the Serial Fixed Baud Rate functions correctly
• Use the HopNet Modems to connect the LogBook to the PC
Note: HopNet Modems are sometimes referred to as “serial extenders”
Verify “Parallel Port” Connectivity
The parallel port connection to the LogBook is used to configure all serial port connections. Thus this
verification is very important.
1. Physically connect the LogBook to the PC using the Parallel Port cable.
2. Launch LogView.
3. In LogView, open the DEVICE pull-down menu.
4. Click on the SELECT LOGBOOK option. A list of configured devices should display.
5. Select “LogBook Parallel.”
6. Click the <ATTACH> button.
Note that a successful connection is required to continue.
Configure the LogBook for “Serial Connections”
The following steps are performed to verify that the Serial Port can be used to connect the PC to the
LogBook.
1. Using the RS232 cable, physically connect the LogBook to the PC’s COM1 Port.
2. Launch LogView.
3. In LogView, open the DEVICE pull-down menu.
4. Click on the SELECT LOGBOOK option. A list of configured devices should display.
5. Select “LogBook Serial.”
6. Click the <ATTACH> button.
Note that a successful connection is required to continue.
