ec-2 Error Codes LogBook User’s Manual
Hardware Errors
The following is a list of fatal hardware errors. LogBook’s ERROR LED indicator (on the front panel)
will blink on/off the number of times indicated by the flash code. If the LogBook is attached to an LBK1,
the corresponding control terminal message will be displayed (otherwise, you must count the LED flashes
to determine the error). Note that flash codes 08, 09, and 17 are associated with multiple errors and thus
require an LBK1 to determine which error applies.
ERROR LED
Flash Code Control Terminal Message
1 NS486 Chip Revision Changed Error
2 Watchdog Timeout Error
3 Flash Startup Code Checksum Error
4 Flash FPGA Code Checksum Error
5 DRAM initialization not complete Error
6 DRAM Sizing Error
7 1 MB DRAM SIMM - Insufficient Memory
8 DRAM Address Line Error
8 DRAM Data Line Error
8 DRAM Integrity Test Error
9 SRAM Address Line Error
9 SRAM Data Line Error
9 SRAM Integrity Test Error
10 SRAM Low Battery Error
11 FPGA Load Error
12 Real Time Clock Low Battery Error
13 DRAM Parity Error
14 Analog Output Slot Empty
15 Calibration Table Verification Error
16 ADC Self Calibration Error
17 TRAP: Divide by Zero, or Divide Overflow
17 TRAP: Debug Trap; Hardware Breakpoint
17 TRAP: Non-Maskable Interrupt (NMI)
17 TRAP: Software Breakpoint
17 TRAP: INT0 Instruct.: Overflow Detected
17 TRAP: BOUND instruction: Range Exceeded
17 TRAP: Invalid Opcode
17 TRAP: Coprocessor Not Available
17 TRAP: Double Fault
17 TRAP: Coprocessor Segment Overrun
17 TRAP: Invalid Task State Segment
17 TRAP: Segment Not Present
17 TRAP: Stack Exception
17 TRAP: General Protection Fault
18 Printf Floating Point Error
19 FPGA PC-Card File Checksum Error
20 FPGA PC-Card File Load Error
DRAM = Dynamic Random Access Memory (the 4- or 16-MB SIMM board)
SRAM = Static Random Access Memory
