RT-3020 User Guide – Rev. F
2-34
1
2
3
4
5
6
7
1
2
3
4
5
6
7
8
9
RD (per DCE Standard Definition)
TD (per DCE Standard Definition)
DTR
NavCom
Reciever
GND
DSR
CTS / 5VDC
RTS
LEMO
DB9S
07-00039-A
PN: 94-310059-3006
Figure 6: NavCom Serial Cable P/N 94-310059-3006
Connect pin 5 to shield of cable at both ends.
