Overview tables

19.4

19

TNC 640 | User's ManualDIN/ISO Programming | 1/2015

633

Cycle
number

Cycle designation

DEF
active

CALL
active

233

Face milling (selectable machining direction, consider the sides)

■

240

Centering

■

241

Single-lip deep-hole drilling

■

247

Datum setting

■

251

Rectangular pocket (complete machining)

■

252

Circular pocket (complete machining)

■

253

Slot milling

■

254

Circular slot

■

256

Rectangular stud (complete machining)

■

257

Circular stud (complete machining)

■

262

Thread milling

■

263

Thread milling/countersinking

■

264

Thread drilling/milling

■

265

Helical thread drilling/milling

■

267

Outside thread milling

■

275

Trochoidal slot

■

Miscellaneous functions

M

Effect

Effective at block...

Start

End

Page

M0

Program STOP/Spindle STOP/Coolant OFF

■

353

M1

Optional program run STOP/Spindle STOP/Coolant OFF

■

574

M2

Stop program/Spindle STOP/Coolant OFF/ CLEAR status display

(depending on machine parameter)/Return jump to block 1

■

353

M3

M4

M5

Spindle ON clockwise

Spindle ON counterclockwise

Spindle STOP

■

■

■

353

M6

Tool change/STOP program run (depending on machine parameter)/

Spindle STOP

■

353

M8

M9

Coolant on

Coolant off

■

■

353

M13

M14

Spindle ON clockwise /coolant ON

Spindle ON counterclockwise/coolant on

■

■

353

M30

Same function as M2

■

353

M89

Vacant miscellaneous function

or

cycle call, modally effective (depending on machine parameter)

■

■

Cycles

Manual

M91

Within the positioning block: Coordinates are referenced to machine

datum

■

354

M92

Within the positioning block: Coordinates are referenced to position

defined by machine tool builder, such as tool change position

■

354

M94

Reduce the rotary axis display to a value below 360°

■

438
