 Auth: Try to authenticate;
 ASSOC: Try to associate;
 Run: Associated successfully.
 WDS Status
The status of WDS. This field is only available in AP Router
Mode.
WAN
 MAC Address
The physical address of the WAN port, as seen from the
Internet.
 IP Address
The current WAN (Internet) IP Address. This field will be blank
or 0.0.0.0 if the IP Address is assigned dynamically and there
is no connection to Internet.
 Subnet Mask The subnet mask associated with the WAN IP Address.
 Default Gateway
The Gateway currently used by the Device is shown here.
When you use Dynamic IP as the connection Internet type, the
Renew button will be displayed here. Click the Renew button
to obtain new IP parameters dynamically from the ISP. And if
you have got an IP address, Release button will be displayed
here. Click the Release button to release the IP address the
Device has obtained from the ISP.
 DNS Server
The DNS (Domain Name System) Server IP addresses
currently used by the Device. Multiple DNS IP settings are
common. Usually, the first available DNS Server is used.
 Online Time
The time that you are online. When you use PPPoE as WAN
connection type, the online time is displayed here. Click the
Connect or Disconnect button to connect to or disconnect from
Internet.
Traffic Statistics
 Sent (Bytes)
Traffic that counted in bytes has been sent out from the current
interface.
 Sent (Packets)
Traffic that counted in packets has been sent out from the
current interface.
 Received (Bytes)
Traffic that counted in bytes has been received from the
current interface.
 Received (Packets)
Traffic that counted in packets has been received from the
current interface.
 System Up Time
The length of the time since the Device was last powered on
or reset. Click the Refresh button to get the latest status and
settings of the Device.
