4. OSD Operation
33
OSD Main Screen Headings
The table below describes the OSD Main Screen headings.
OSD Navigation
Š To dismiss the menu, and deactivate OSD, click the X at the upper right
corner of the OSD window; or press [Esc] .
Š To log out, click F8 at the top of the main screen, or press [F8] .
Š To move up or down through the list one line at a time, click the up and
down triangle symbols (
ST ) or use the up and down arrow keys. If there
are more list entries than what can appear on the main screen, the screen
will scroll.
Š To move up or down through the list one screen at a time, click the up and
down arrow symbols (
ÏÐ ), or use the [Pg Up] and [Pg Dn] keys. If there
are more list entries than what can appear on the main screen, the screen
will scroll.
Š To bring the KVM focus to a port, double click it, or move the highlight
bar to it then press
[Enter] .
Š After executing any action, you automatically go back to the menu one
level above.
Heading Description
SN--PN This column lists the port ID numbers (station number - port
number) for all the KVM ports on the installation. The simplest
method to access a particular computer is move the highlight bar to
it, then press
[Enter] .
QV If a port has selected for quick view scanning (see Set Quick View
Ports , page 40), an arrowhead displays in this column.
The computers that are powered on and are online have a sun
symbol in this column.
NAME If a port has been given a name (see Edit Port Names , page 40), its
name appears in this column.
