CL5808/CL5816 User Manual
34
OSD Functions
OSD functions are used to configure and control the OSD. For example, you
can rapidly switch to any port, scan selected ports, limit the list you wish to
view, designate a port as a quick view port, create or edit a port name, or make
OSD setting adjustments.
To access an OSD function:
1. Either click a function key field at the top of the main screen, or press a
corresponding function key on the keyboard.
2. In the submenus that appear, make your choice either by double clicking it,
or moving the highlight bar to it, then pressing
[Enter]
.
3. Press
[Esc]
to return to the previous menu level.
F1: GOTO
Clicking the
F1
field or pressing
[F1]
activates the GOTO function. GOTO
allows you to switch directly to a port either by keying in the port's
Name
, or
its
Port ID
.
To use the name method, key in
1
; key in the port's
Name
; then press
[Enter]
.
To use the port ID method, key in
2
; key in the
Port ID
; then press
[Enter]
.
Note:
You can key in a partial name or port ID. In that case, the screen will
show all the computers that the user has
View
rights to (see
SET
ACCESSIBLE PORTS
, page 39), that match the name or port ID
pattern, regardless of the current list settings (see
F2 LIST
, page 35, for
details).
To return to the OSD main screen without making a choice, press
[Esc]
.
