4. OSD Operation

Setting

Function

SET USER
LOGIN
(continued)

To record a fingerprint

1. Select an item from the list and double-click it, or move the high-

light bar to it and press

[Enter]

2. Swipe the selected finger across the reader 3 times as directed.
3. Once the fingerprint is successfully recorded, you have the

option of recording another.

Note:

1. Pressing F1 deletes the highlighted fingerprint from

memory.

2. Pressing F2 deletes all fingerprints for the current user

from memory.

3. Pressing F3 allows you to edit the name of the

highlighted fingerprint.

4. Pressing F5 deletes the highlighted fingerprint’s name.

SET LOGIN MODE:

Note:

This setting is only available on models with a fingerprint

reader.
Use this function to select the user login mode: either

PASSWORD

OR FINGERPRINT

(where either the username and password or a

fingerprint can be used to log in), or

PASSWORD + FINGERPRINT

(where the username and password followed by a fingerprint must
be used).
In PASSWORD + FINGERPRINT mode, if the fingerprint does not
match the username, the user will not be able to log in. This mode
provides better security than PASSWORD OR FINGERPRINT
mode.

SET
ACCESSIBLE
PORTS

This function allows the administrator to define user access to the
computers on the installation on a port-by-port basis.

For each user, select the target port; then press the

[Spacebar]

cycle through the choices:

(full access),

(view only), or blank.

Repeat until all access rights have been set, then press

[Enter]

The default is

for all users on all ports.

Note:

1. A blank setting means that no access rights are granted.

The port will not show up on the user's LIST on the main
screen.

2. The administrator always has full access to all ports.

SET LOGOUT
TIMEOUT

If there is no input from the console for the amount of time set with
this function, the user is automatically logged out. A login is
necessary before the console can be used again.
This enables other users to gain access to the computers when the
original user is no longer accessing them, but has forgotten to log
out. To set the timeout value, key in a number from 1–180 minutes,
then press

[Enter]

. The default setting of 0 disables this function.
