CL5808/CL5816 User Manual
76
Clear Login Information
If you are unable to perform an Administrator login (because the Username and
Password information has become corrupted, or you have forgotten it), you can
clear the login information with the following procedure.
1. Power off the switch and remove the top cover from the unit chassis.
2. Short jumper J17 (labeled Default Password ) on the switch's main board
.
3. Power on the switch.
When you power the switch on, the following message appears on the
LCD display:
USERNAME AND PASSWORD INFORMATION HAS BEEN CLEARED.
PLEASE POWER OFF THE SWITCH, REMOVE THE JUMPER, CLOSE
THE CASE, THEN RESTART.
After you start back up, the OSD login function acts exactly the way it did the
first time the switch was run (see
Overview , page 31) and you can reset
passwords for the Administrators and Users.
