CL5808/CL5816 User Manual
78
Optional Rack Mounting
For convenience and flexibility, three optional rack mounting kits are available,
as shown in the following table:
Standard - Long
To install the long bracket standard rack mount kit, simply replace the short L
brackets on the standard rack mount kit with the long ones, and mount the
switch according to the instructions given for
Standard Rack Mounting ,
page 12.
Easy Installation
With an Easy-Installation , kit, one person can mount the switch. To install the
Easy-Installation kit, do the following:
1. Remove the standard L brackets, and the side mounting brackets from both
sides of the switch.
Bracket Type Size (cm)
Standard Installation – Long 70.0 – 105.0
Easy Installation – Short 57.0 – 70.0
Easy Installation – Long 68.0 – 105.0
